Harley-Davidson Low Rider S Parts & Accessories

Low Rider S parts: five flat years, then 2025

779 Low Rider S are taxed in the UK and 260 more are on SORN, up 68 per cent in five years. One code, FXLRS, since 2020; all seven catalogue years are UK years.

Flat to 2024, then the 2025 swap

A 2020 to 2024 S loses one part a year at most; 2022 swaps little more than the fuel cap kit, 61100132 to 61100210 or 61100211. 2025 is the break, 97 parts out, 41 in, 84 per cent kept. All 45 hand grips end at 2024 and 25 new ones start, so no grip fits both a 2024 and a 2025 Low Rider S. The Moto Bar 55800856, Fused 55801016 and Fused Lo 55801057 give way to the Hollywood handlebar 55801579, the lever kits to the adjustable 36700307, Öhlins shock 54000325 to 54000384, and the Stage II kits to the SE8-511 cam 25400476, Stage II 92500132 and 92500133 and Stage IV 92500146 big-bore kits.

One list for the S and the ST

636 of the 662 genuine parts we list for the S also fit the Low Rider ST: every seat, sissy bar, rack, rotor, headlamp and engine part is the same number on both. The 26 S-only parts are what a fairing and hard bags rule out, the swingarm bag 90201567 or 90201568, throw-over supports 90201777 and the three bars above. One gotcha on both: front axle nut covers such as 43000177 need installation kit 43000159 on the inverted fork.

Sissy bar, rack, bags: the order matters

The HoldFast uprights 52300432, 52300434 and 52300435 need docking kit 52300645 or 52300646 under them, and the Sport luggage rack 50300130B or 50300131B hangs on that upright. The S ships with a solo seat, so choose the sissy bar first, then one of the eight two-up seats, Tallboy 52000305 or Reach 52000354 among them. Bags on a 2020 to 2024 S need an indicator relocation kit: the rigid saddlebags 90202534DH name 67801349; the Overwatch 90202332 and Defender 90202763 ask for one too. A 2025-on S needs none, its tail light carries the indicators, and its rigid bags are 90202838DH.

Close relatives

The Street Bob takes 604 of the S’s 662 parts, the Sport Glide 579, the Breakout 571 and the Fat Bob 114 541; the El Diablo is an ST in the parts book, 577 of its 597.
