288-24 Offset transmission sprocket 24t
incl. VAT
Chapter members save 14% · Sign in for member pricing
Estimated delivery: 3–15 working days
Authorised
Iron City Dealer
14-Day Returns
Easy & hassle-free
Secure Checkout
256-bit encryption
Free UK Delivery
On orders over £100
Specifications
- Brand
- PBI
- Part Number
- 288-24
- OEM Reference
- —
- Pack Quantity
- Each
- Category
- Sprockets Transmission Offset
- VAT Rate
- 20%
About This Product
PBI offset transmission sprocket, 24 tooth. It carries a 1.060 inch offset to kick the drive line outboard for clearance on a wide rear tyre chain conversion. CNC machined from 8620 alloy steel, heat-treated and nickel-plated. Fits 1986 through 2006 5-speed Big Twins, excluding 2006 Dyna models, 1991 through 2006 XL Sportsters, and Buell models. Watch the lockplate bolt location on 1991 through 1992 XL models; it is different.
Manufacturer part number: 288-24.
Fitment
71 models86-06 5-speed Big Twin (Excl. 2006 Dyna); 91-06 XL Sportster; Buell. (With rear chain conversion)
Dyna 8 models
| Brand | Year | Model |
|---|---|---|
| Harley-Davidson | 1999 | Dyna Glide Convertible FXDS-CONV |
| Harley-Davidson | 1993–2005 | Dyna Low Rider FXDL |
| Harley-Davidson | 1991 | Dyna Sturgis FXDB |
| Harley-Davidson | 1996–1999 | Dyna Super Glide Convertible FXDS |
| Harley-Davidson | 1995–2005 | Dyna Super Glide FXD |
| Harley-Davidson | 1999–2004 | Dyna Super Glide Sport FXDX |
| Harley-Davidson | 1993–2005 | Dyna Wide Glide FXDWG |
| Harley-Davidson | 1992 | Super Glide Custom FXDC |
FXR 18 models
| Brand | Year | Model |
|---|---|---|
| Harley-Davidson | 1989–1990 | FXR Convertible FXRS |
| Harley-Davidson | 1985–1987 | FXR Custom FXRC |
| Harley-Davidson | 1986–1990 | FXR Low Glide FXRS |
| Harley-Davidson | 1989–1990 | FXR Low Rider FXLR |
| Harley-Davidson | 1986–1993 | FXR Sport FXRS-SP |
| Harley-Davidson | 1986–1988 | FXR Super Glide FXR |
| Harley-Davidson | 1986 | FXR Touring FXRD |
| Harley-Davidson | 1986–1990 | FXR Touring FXRT |
| Harley-Davidson | 1991–1992 | Low Rider Convertible FXRS |
| Harley-Davidson | 1991–1992 | Low Rider Custom FXLR |
| Harley-Davidson | 1992 | Low Rider FXRS |
| Harley-Davidson | 1991–1993 | Low Rider Sport Edition FXRS-SP |
| Harley-Davidson | 1986–1990 | Police Low Rider FXRP |
| Harley-Davidson | 1991 | Sport Glide FXRT |
| Harley-Davidson | 1993 | Super Glide Convertible FXRS |
| Harley-Davidson | 1992–1993 | Super Glide FXR |
| Harley-Davidson | 1991–1994 | Super Glide Police (Fairing) FXRP |
| Harley-Davidson | 1992–1994 | Super Glide Police (Windshield) FXRP |
Police 4 models
| Brand | Year | Model |
|---|---|---|
| Harley-Davidson | 1991–1995 | Electra Glide Standard Police (Fairing) FLHTP |
| Harley-Davidson | 1992–1995 | Electra Glide Standard Police (Windshield) FLHTP |
| Harley-Davidson | 1996 | Electra Glide Standard Police FLHTP |
| Harley-Davidson | 1996–1999 | Road King Police FLHPI |
Softail 15 models
| Brand | Year | Model |
|---|---|---|
| Harley-Davidson | 1986 | FX Wide Glide FXWG |
| Harley-Davidson | 1992–2006 | Fat Boy FLSTF |
| Harley-Davidson | 1992–2002 | Heritage Softail Classic FLSTC |
| Harley-Davidson | 1994–1996 | Heritage Softail Nostalgia FLSTN |
| Harley-Davidson | 1997–1999 | Heritage Springer FLSTS |
| Harley-Davidson | 1999–2006 | Night Train FXSTB |
| Harley-Davidson | 1987–1999 | Softail Custom FXSTC |
| Harley-Davidson | 2005–2006 | Softail Deluxe FLSTN |
| Harley-Davidson | 1990 | Softail Fat Boy FLSTF |
| Harley-Davidson | 1988–1990 | Softail Heritage Classic FLSTC |
| Harley-Davidson | 1986–1990 | Softail Heritage FLST |
| Harley-Davidson | 1988–1990 | Softail Springer FXSTS |
| Harley-Davidson | 1986–2006 | Softail Standard FXST |
| Harley-Davidson | 1991–2006 | Springer Softail FXSTS |
| Harley-Davidson | 1995–1997 | Springer Softail FXSTSB |
Sportster 8 models
| Brand | Year | Model |
|---|---|---|
| Harley-Davidson | 1996–2006 | Sportster 1200 Custom XL1200C |
| Harley-Davidson | 1996–2003 | Sportster 1200 Sport XL1200S |
| Harley-Davidson | 1991–2003 | Sportster 1200 XL1200 |
| Harley-Davidson | 1998–2006 | Sportster 883 Custom XL883C |
| Harley-Davidson | 1991–1994 | Sportster 883 Deluxe XL883DLX |
| Harley-Davidson | 1991–2003 | Sportster 883 Hugger XL883HUG |
| Harley-Davidson | 1991–2006 | Sportster 883 XL883 |
| Harley-Davidson | 2002–2006 | Sportster 883R XL883R |
Touring 18 models
| Brand | Year | Model |
|---|---|---|
| Harley-Davidson | 1992–2005 | Electra Glide Classic FLHTC |
| Harley-Davidson | 1999–2006 | Electra Glide Classic FLHTCI |
| Harley-Davidson | 1992–1994 | Electra Glide Sport FLHS |
| Harley-Davidson | 1995–2006 | Electra Glide Standard FLHT |
| Harley-Davidson | 1998–2003 | Road Glide FLTR |
| Harley-Davidson | 1998–2006 | Road Glide FLTRI |
| Harley-Davidson | 1998–2006 | Road King Classic FLHRCI |
| Harley-Davidson | 2004–2005 | Road King Custom FLHRS |
| Harley-Davidson | 1994–2006 | Road King FLHR |
| Harley-Davidson | 1996 | Road King FLHRI |
| Harley-Davidson | 2006 | Street Glide FLHX |
| Harley-Davidson | 1991–1995 | Tour Glide Ultra Classic FLTCU |
| Harley-Davidson | 1986–1990 | Touring Electra Glide Classic FLHTC |
| Harley-Davidson | 1987–1990 | Touring Electra Glide Sport FLHS |
| Harley-Davidson | 1986–1988 | Touring Tour Glide Classic FLTC |
| Harley-Davidson | 1989 | Touring Tour Glide Classic Ultra FLTCU |
| Harley-Davidson | 1991–1997 | Ultra Classic FLHTCU |
| Harley-Davidson | 1996–2006 | Ultra Classic FLHTCUI |
Planning other changes? Find your model in the bike customiser.
